Thông tin chi tiết sản phẩm:
|
| YKQ: | Dòng van điện từ chất lỏng thu nhỏ | 3435: | Đặc điểm cấu trúc thân van (Loại ba chiều) |
|---|---|---|---|
| D: | loại đóng thông thường | 012: | Điện áp định mức DC12V |
| G91: | Vị trí đầu cuối của ổ cắm | Biểu mẫu đường dẫn: | Hai chiều Ba chiều (3 cổng) |
| trạng thái làm việc: | NC thường đóng | ||
| Làm nổi bật: | two-way miniature electromagnetic valve,three-way direct-acting fluid pump valve,miniature electromagnetic valve with warranty |
||
Product Description:
YJJ YKQ3435D012D-G91 Two-way Three-way Miniature Direct-Acting Electromagnetic Valve (Fluid Pump Valve)
Features:
I. Basic Information
Category: Two-way three-way miniature direct-acting electromagnetic valve (fluid pump valve)
Model Interpretation:
YKQ: Miniature fluid electromagnetic valve series
3435: Valve body structure specification (three-way type)
D: Direct current coil
012: Rated voltage DC12V
D: Normally closed type
G91: Terminal position of output line + Customized version of sealing material (silicone sealing) Table
Project Parameter Value
Path Form Two-way three-way (3-way)
Working State Normally Closed NC
Rated Voltage DC 12V (012 code)
Coil Power 2.2W
Working Current ≤ 185mA
Working Pressure 0 - 0.8 MPa (0 - 8 bar)
Piping Diameter and Hole Diameter 1.2 mm
Applicable Medium Dry air, nitrogen, pure water, weakly corrosive clean liquids
Sealing Material Silicone (G91 configuration), resistant to weak acids and alkalis
Valve Body Material PPS engineering plastic
Response Time ≤ 10ms, stable high-frequency switching
Air Tightness Negative pressure leakage < 2mmHg/min, no leakage during pressure retention
Working Temperature Medium 0 - 60℃; Environment -10℃ - +55℃
Mechanical Life ≥ 2000 million on-off cycles
Connection Interface External diameter of the flexible hose 3mm
Protection Grade IP54
III. Product Features
Ultra-small size, suitable for integration on the instrument gas path board;
Low power consumption DC12V, suitable for battery-powered equipment;
Three-way switching structure, one inlet, two switching exhaust/output;
Silicone sealing without leakage, suitable for vacuum and micro-pressure control;
Resistant to high-frequency repeated start-stop, no overheating of the line coil for a long time.
IV. Main Applications
1. Medical analysis equipment (main scenarios)
Blood gas analyzer, biochemical instrument gas path switching valve;
Respirator, nebulizer, air pressure therapy instrument gas flow cut-off control;
Negative pressure collection tube, vacuum blood collection equipment vacuum switching.
2. Environmental detection instruments
Gas sensor gas path switching (hydrogen sulfide, sulfur dioxide detection instrument);
Smoke analyzer, atmospheric sampling pump gas path distribution valve;
Automatic sample injection gas path electromagnetic valve.
3. Industrial automation micro air pump matching
Micro vacuum pump, diaphragm air pump matching switching valve;
Vacuum suction cup, micro pneumatic gripper air flow control;
Leak detection equipment micro gas path on-off switch.
4. Other industries
Beauty equipment, air pump module, water valve water path switching;
Laboratory fluid micro pipeline on-off control.
Specifications:
| Rated Voltage | DC 12V (Code 012) |
| Coil Power | 2.2W |
| Working Current | ≤ 185mA |
| Working Pressure | 0 - 0.8 MPa (0 - 8 bar) |
| Bore Diameter | 1.2 mm |
