Thông tin chi tiết sản phẩm:
|
| Khí phát hiện: | metan CH4 | Nguồn điện: | DC (3,2-3,6) V |
|---|---|---|---|
| Dòng điện làm việc: | < 300mA | Mức độ giao diện: | 3.0v |
| Làm nổi bật: | Methane CH4 gas sensor no calibration,Long lifespan methane gas sensor,MH-Z9041A methane sensor with warranty |
||
MH-Z9041A Methane CH4 Gas Sensor No Need Calibration Long Lifespan
Description
MH-Z9041A laser CH4 gas sensor (hereinafter referred to as the sensor) is a domestic methane sensor, based on tunable laser gas absorption technology (TDLAS) technology to detect methane gas, internal use of cross-beam light path structure, with excellent gas selectivity, no oxygen dependence, water vapor resistance. Anti-poisoning, long life, etc. Built-in temperature control algorithm, temperature compensation algorithm, to achieve accurate measurement of methane gas; With serial port output interface, easy to use. The sensor is a high performance sensor which combines mature laser gas absorption detection technology with stable optical path design and circuit design.
Application
Methane gas alarm for home use
Features
Resistance to water vapor, no poisoning
Response to CH4 gas only, no response to other gases
No need calibration, long lifespan
High accuracy, resolutio
Specification:
|
Detection Range
|
3-100%LEL (can be customized) |
| Detection Accuracy | ±3%LEL @25℃ |
| Output signal | Serial port (UART) (TTL level 3.0V) |
| Warm-up time | 15s |
| Response time | T90< 15s |
| Working conditions | -13~58℃① 0-95%RH(no condensation) 80kpa~116kpa |
| Storage temperature | -20~60℃ |
| Size | 76.5mmX21mmX14.1mm |
| Weight | < 20g |
| Life | > 10 years |
