Thông tin chi tiết sản phẩm:
|
| Điện áp nguồn: | 3,25 - 5,5V | điện áp cung cấp: | 3.3v |
|---|---|---|---|
| Thông số kỹ thuật hiện tại: | Dòng điện cực đại 100mA | Tiêu thụ điện năng: | 35mW |
| Phương pháp giao tiếp: | Sử dụng UART | Thông số kỹ thuật giao diện: | Được trang bị 4 0,5 |
| Loại tham số: | Các chỉ số cụ thể | Nhiệt độ hoạt động: | 0 ℃ - 50 |
| Làm nổi bật: | high-speed carbon dioxide sensor,medical CO2 monitoring sensor,YJJ SprintIR-R-5 gas sensor |
||
Product Description:
YJJ SprintIR-R-5 High-Speed Carbon Dioxide Sensor Is Used For Medical Monitoring
Features:
SprintIR-R-5 is a high-speed carbon dioxide sensor launched by SST. It employs patented NDIR solid-state LED optical technology and is suitable for scenarios such as medical monitoring and food packaging that have high requirements for measurement speed. The following is a detailed parameter description based on the official disclosure of this product:
Core detection parameters
Parameter category Specific indicators
Detected gas Carbon dioxide (CO₂)
Measurement range Fixed range 0 - 5% vol CO₂
Measurement accuracy ±70ppm and ±5% for additional readings, stable measurement accuracy
Resolution 10ppm, capable of accurately capturing minute changes in carbon dioxide concentration
Measurement noise Without digital filtering, measurement noise is lower than 10% of the reading
Measurement rate 50 measurements per second (50Hz), the fastest measurement speed among commercial carbon dioxide sensors on the market
First reading time less than 0.2 seconds, can quickly obtain valid data after startup
Response time Dependent on gas flow rate, with a flow adapter, it can ensure high-speed response performance
Electrical parameters
Parameter category Specific indicators
Power supply voltage 3.25 - 5.5V, official recommendation 3.3V power supply
Current specification Peak current 100mA, average current less than 15mA
Power consumption Only 35mw, low power consumption feature suitable for portable and battery-powered devices
Communication method Uses UART communication interface, convenient for integration with various devices
Interface specification Includes 4 0.5 square millimeter pins, corresponding to UART receive input, UART send output, ground, and power voltage
Environmental and lifespan parameters
Parameter category Specific indicators
Operating temperature 0℃ - 50℃, suitable for most common working temperature environments
Operating humidity 0 - 95% RH, must be used in an environment without condensation
Operating pressure Compatible with a pressure range of 500mbar - 2bar, with a flow adapter, it can work stably
Pressure dependence Under normal atmospheric pressure, for every change of 1 mbar, the measurement value deviation is 0.15% of the reading
Storage temperature - 40℃ - 70℃, no special maintenance required during storage
Lifespan Expected lifespan of the sensor exceeds 15 years, long-term use stability is strong
Physical and other parameters
Parameter category Specific indicators
Shape size Diameter 23.8mm, length 24mm, small size suitable for integration installation
Overall weight Only 7.5g, almost no increase in the overall load of the device
Installation accessories Standard flow adapter included, customizable adapters can be selected according to installation requirements
Environmental compliance Complies with RoHS and REACH environmental standards, environmentally friendly
Warranty period Provide 90-day product warranty service, in accordance with CO2 Meter relevant terms
Specifications:
| Gas Detection | CO2 |
| Measurement Range | 0-5% vol CO₂ |
| Measurement Accuracy | ±70ppm and ±5% |
| Resolution | 10ppm |
| Measurement Noise | Without digital filtering |
