Thông tin chi tiết sản phẩm:
|
| S9219: | φ11,3 mm (hình tròn) | S9219-01: | 3,6×3,6 mm (vuông) |
|---|---|---|---|
| Số điểm ảnh: | 1 (pixel đơn) | Loại bao bì: | Bao bì kim loại |
| Phương pháp tản nhiệt: | Loại không làm mát | Điện áp ngược (giá trị tối đa): | 5 v |
| Phạm vi bước sóng nhạy cảm: | 380–780nm | Bước sóng độ nhạy tối đa: | 550nm |
| Làm nổi bật: | silicon photodiode visible light detection,infrared photoelectric sensor silicon,photodiode for visible light sensing |
||
Product Description:
YJJ S9219 S9219-01 Silicon Photodiode Is Used For Visible Light Detection
Features:
S9219 photodiode is a silicon photodiode produced by Hamamatsu Photonics. It is mainly used for visible light detection and features high sensitivity and fast response characteristics. The following is the detailed description of its core parameters:
Basic parameters
Light-receiving surface:
S9219: φ11.3 mm (circular)
S9219-01: 3.6×3.6 mm (square)
Pixel count: 1 (single pixel)
Packaging type: Metal packaging, with CIE filter (visible light filtering)
Heat dissipation method: Non-cooling type
Electrical characteristics
Reverse voltage (maximum value): 5 V
Sensitivity wavelength range: 380–780 nm (visible light)
Maximum sensitivity wavelength (typical value): 550 nm (green light)
Sensitivity (typical value):
S9219: 0.24 A/W
S9219-01: 0.22 A/W
Dark current (maximum value):
S9219: 500 pA
S9219-01: 50 pA
Rise time (typical value):
S9219: 2.5 μs
S9219-01: 0.5 μs
Capacitance (typical value):
S9219: 1100 pF
S9219-01: 150 pF
Other characteristics
Spectral sensitivity: Similar to the human eye response curve, the peak is at 550 nm
Measurement conditions:
Temperature: 25°C
Dark current test: VR = 10 mV
Rise time test: VR = 0 V, f = 1 kHz
Application scenario
Suitable for visible light detection fields such as optical measurement, optical communication, and environmental monitoring, which require rapid response and high sensitivity.
Specifications:
| Peak wavelength | 550 nm |
| Spectral response range | 380 - 780 nm |
| Photo sensitivity | 0.22 A/W |
| Dark current | Maximum 50 pA |
